Message
associated with.. meaning.. ..possible action
Voice Alarm comms
failed
Port 1 / Node x
Panel's Serial Link There is a serial link wiring fault between Vigilon
panel 'Port 1' and DOM/Comprio. Other Vigilon panels
in the connected network will indicate the 'Node'
number of the panel connected to DOM /Comprio.
Check the serial link is working, ensure:
¨
Serail link cable is connected to DOM to
socket TWI
¨
Serial link cables are connected to the two 9
way D Type connectors on the Adapter
TWI-RS232 and
¨
Serail link cable is wired correctly at a
Vigilon/Compact panel to terminals Tx, Rx
and 0V.
Voice Alarm comms
failed
Port 1 / Node x
Panel's Serial Link There is a serial link wiring fault has been restored
between Vigilon panel 'Port 1' and DOM/Comprio.
Other Vigilon panels in the connected network will
indicate the 'Node' number of the panel connected to
DOM /Comprio.
-
Voice Alarm common
fault Node x
Connected D1 Voice Alarm
system
There is a common fault, that is any fault in D1 Voice
Alarm system, for example Speaker line fault,
Amplifier fault, Mains power fault, etc.
The ERROR LED is lit at the DOM/Comprio
connected via serial link to Vigilon panel.
Find the cause of common fault at a D1 Voice
Alarm system:
¨
Refer to user guides for D1 Voice Alarm
system modules to locate the fault.
¨
Once the fault is rectified the fault message
and notice fault indications are removed at
both Vigilon and D1 Voice Alarm system.
Voice Alarm
configuration fault
Nos. 17
Configuration fault at a D1
Voice Alarm System
This message and indication is given at Vigilon panel
of a configuration fault in a D1 Voice Alarm system.
The affected output (VOP) in this case No 17 is not
recognised.
Test for a configuration error which occurs
when a non existent or not configured properly
Virtual Output Point is made active.
¨
Confirm the VOP displayed as being faulty is
non existent.
¨
Rectify the configuration at Vigilon and/or at
the D1 Voice Alarm system.
¨
Repeat this test to ensure the revised
configuration works. Check to ensure the
fault has cleared.
Warm restart MCC / MCB
(main control card)
The 5V rail has seen a dip activating the watchdog or
the button has been pressed on MCC / MCB or panel
power reconnected.
-
4188-856_issue 7_07/15_Generic Vigilon (Compact + VA) Comms. 137
Vigilon 4/6 loops & Compact (VA) panels & network nodes
Appendix B - Message Action List
