Figure 19. Passcode screen
Warning: Thefactory-setpasscodesmustberesettoprevent
unauthorizedaccesstothetransmitter’smenus.
WhenthePasscodeScreenisdisplayed,therstpasscode
digitishighlighted�Usethe switchestoincrementor
decrementthroughthevalues�Oncethecorrectvalueis
displayedfortherstdigit,
acceptsthevalueandmovesto
thenextdigitor
movestothepreviousdigitofthepasscode�
Figure 20. Entering the passcode
Repeatforeachoftheremainingdigitsinthepasscode�Ifthe
passcodeisnotenteredcorrectly,theInvalidPasscodescreen
isdisplayedandtheuserisreturnedtotheGeneralStatus
screen�
Figure 21. Invalid Passcode screen
1.4.4 Displaying Transmitter Information
WhileintheGeneralStatusdisplay,swipethemagnetoverthe
magneticswitch
todisplayinformationaboutthetransmitter�
TheGeneralStatusdisplaywillreplacethebargraphinthe
lowerportionofthescreenwiththeunit’sserialnumber,the
dateandtime,andtheunit’spartnumber�
Figure 22. General Status Screen with Unit Information
