HORA MC55/24 - 5 Commissioning

5 Commissioning
Linear actuators MC55
18 Version 3.3 - November 2014 Operating Manual
5 Commissioning
WARNING
Risk of injury from electric shock by live parts!
When the power supply is on there is a danger of electric shock due to live parts.
• Prior to commencing any work, ensure that the actuator is safely disconnected
from the power supply system.
• Secure against unauthorised restarting.
The jumpers on the plug-in jumper are used to set the operating parameters
(113). The plug-in jumper and the jumpers are underneath the push-fit PCB (107)
in the actuator housing (1).
 4.4 Assembling/disassembling the cover on page 13
 4.5.2 Remove push-fit PCB and transformer MC55/230 on page 17
113 Plug-in jumper JP1-JP6 MC55Y 113 Plug-in jumper JP2-JP5 MC55/24, MC55/230
diagram 9 Plug-in jumper position on the main PCB
JP6
JP5
JP4
JP3
JP2
JP1
24 V / 230 V
Y
JP6
JP5
JP4
JP3
JP2
JP1
JP2
JP3
JP4
JP5
113
