2 Product Specification
Linear actuators MC100 • MC103
10 Version 2.1 - March 2011 Operating Manual
2.5 Technical data
Type MC100/24, MC103/24 MC100/230, MC103/230
Supply voltage: 24 V AC ± 10%
24 V DC ± 10%
115 V AC ± 10%
230 V AC + 6% -10%
Power consumption 6VA 12VA
Weight 2.5 kg 2.5 kg
Dimensions See technical data sheets
Stroke max. 20 mm max. 20 mm
Frequency 50/60 Hz ± 5% 50/60 Hz ± 5%
Ambient temperature 0 to +60°C 0 to +60°C
Enclosure protection IP 54 IP 54
Operating mode S3-50% ED S3-50% ED
Actuating time 12, 9, 4, 1.9 s/mm 12, 9, 4, 1.9 s/mm
Actuating force 1.0 kN
During 24 V DC the
specified actuating force
can only be reached with
the help of an aligned AC
voltage.
1.0 kN
table 1 Technical data
Input signal Y/
Resistance of load
• 0 … 10 V DC / 77 k

• 2 … 10 V DC / 77 k
• 0 … 20 mA / 510 
• 4 … 20 mA / 510 
Output signal X/
Load rating
• 0 … 10 V DC / resistance of load 1200 , I
max.
8 mA
• 0 … 20 mA / resistance of load
500  -
with accessory PCB for output signal (111)
• 4 … 20 mA / resistance of load 500  -
with accessory PCB for output signal (111)
Response signal R/ load
rating
• 24 V DC / minimum impedance
480 I
max.
35 mA
Cable impedance between
B1 and B2
• max. 10

table 2 Technical data signals
