This section describes the following connectors on the system unit’s
rear panel:
• Audio connectors (including headphones and microphone)
• PS/2 keyboard and mouse connectors
• HP parallel Centronics I/O connector
• 802.3 AUI LAN connector
• 802.3 TP (Twisted Pair) LAN connector
• RS-232C serial I/O connectors
• SCSI connectors including fast, wide differential, or ultra,
wide–SE (J2240 only) and narrow single-ended SCSI
• TOC button
• Power cord connector
• HP–HIL connector (J282 only)
NOTICE: To maintain FCC/EMI compliance, verify that
all cables are fully seated and properly fastened.
Figure 1–4 shows the locations of the connectors on the system unit’s
rear panel.
