1-11
TOC
Button
(not shown)
Fast, Wide DifferenĆ
tial, or Ultra, Wide-
SE SCSI Connector*
Narrow, SE SCSI
Connector*
Keyboard
Connector
AUI LAN
Connector
Twisted Pair
Connector
(labeled UTP)
RSĆ232C
Connectors
Graphics
Connector
Power
Connector
Parallel I/O
Connector
*SCSI Connectors are
shown with terminators
attached, as they are
shipped from the factory.
**See Figure 1-5 for detail
on Audio Connectors.
Mouse
Connector
Audio
Connectors**
HP-HIL
Connector
(J282 only)
Figure 1–4. System Unit Rear Panel Connectors
