Chapter 1 Getting Started
Making Measurements
1-16 Operating Guide
1
Selecting Input Impedance
Channel 2’s input impedance is now set to 50
Ω
.
NOTE
The “arrow” keys can also be used to toggle the state of toggle keys
(DC/AC, 50
Ω
/1M
Ω
, etc.) as indicated by the flashing indicator within the
arrow keys. However, for simplicity in this procedure, use the
corresponding toggle key to change states.
If you want to change the input impedance back to the default
1M
Ω
impedance, perform the following step.
50Ω
1MΩ
50Ω
1MΩ
