Chapter 2 Operating Your Universal Counter
Front Panel Display Messages
Operating Guide 2-75
2
Menu Messages
Table 2-5. Menu Messages
Display Message Description
(AC COUPLED)
You have selected the VOLT PEAKS function to be measured on a channel which
is ac coupled.
BAD CODE
The Counter’s calibration is secured and you have entered an incorrect code.
CAL ABORTED
Calibration was aborted because of HP-IB or the user pressing a key besides the
Enter key.
CAL SECURE
You are in the Calibration menu, and the first menu item indicates that the
Counter is secure against calibration.
CAL UNSECURE
You are in the Calibration menu, and the first menu item indicates that the
Counter is unsecure for calibration.
CALIBRATING
You have invoked calibration from the Calibration menu item
CAL:
, and the
Counter is currently performing the calibration.
1
EEPROM FAIL
You have requested that a Counter setting which is stored in the EEPROM
(
HP-IB:
,
BAUD:
,
PARITY:
,
SW PACE:
,
DTR:
,
SHOW 9 AS:
, or
CAL:
) be
updated, and a hardware failure has resulted.
GAIN 1 FAIL
You have invoked the
GAIN 1 ?
choice from the Calibration menu item
CAL:
, and
the calibration failed.
GAIN 1 PASS
You have invoked the
GAIN 1 ?
choice from the Calibration menu item
CAL:
, and
the calibration passed.
GAIN 2 FAIL
You have invoked the
GAIN 2 ?
choice from the Calibration menu item
CAL:
, and
the calibration failed.
GAIN 2 PASS
You have invoked the
GAIN 2 ?
choice from the Calibration menu item
CAL:
, and
the calibration passed.
IN REMOTE
You have pressed a key (other than Local) while in remote.
LOCAL LCKOUT
You have pressed the Local (Save & Print) key while in remote with local lockout.
OFFS 1 FAIL
You have invoked the
OFFS 1 ?
choice from the Calibration menu item
CAL:
,
and the calibration failed.
OFFS 1 PASS
You have invoked the
OFFS 1 ?
choice from the Calibration menu item
CAL:
,
and the calibration passed.
