193
Field Descri
tion
Subvlan ID Sub-VLAN ID.
VLAN Type VLAN type (static or dynamic).
Route Interface
Indicates whether a VLAN interface is configured or not for the sub-VLAN or
super VLAN.
IPv4 address
IPv4 address of the VLAN interface. This field for a sub-VLAN is the same as
that for the super VLAN. This field is not displayed when no VLAN interface is
configured for the super VLAN.
IPv4 subnet mask
Subnet mask of the IPv4 address. This field for a sub-VLAN is the same as that
for the super VLAN. This field is not displayed when no VLAN interface is
configured for the super VLAN.
IPv6 global unicast
address(es)
Global unicast IPv6 address of the VLAN interface (available only when an
IPv6 address is configured for the VLAN interface).
Tagged Ports Ports through which VLAN packets are sent tagged.
Untagged Ports Ports through which VLAN packets are sent untagged.
subvlan
Syntax
subvlan vlan-list
undo subvlan [ vlan-list ]
View
VLAN view
Default level
2: System level
Parameters
vlan-list: Specifies a sub-VLAN list, in the format of vlan-list = { vlan-id1 [ to vlan-id2 ] }&<1-10>, where
vlan-id1 and vlan-id2 represent the sub-VLAN IDs rand each range from 1 to 4094, and &<1-10>
indicates that you can specify up to 10 vlan-id1 [ to vlan-id2 ] parameters. The vlan-id2 argument cannot
be smaller than the vlan-id1 argument.
Description
Use subvlan to associate the super VLAN with sub-VLANs specified by vlan-list.
Use undo subvlan to remove the association.
Verify that the sub-VLANs already exist before associating them with a super VLAN.
You can add/remove a port to/from a sub-VLAN already associated with a super VLAN.
If you use the undo subvlan command without vlan-list specified, you will remove the association
between the specified super VLAN and all its sub-VLANs.
If you use the undo subvlan command with vlan-list specified, you will remove only the association
between the super VLAN and the sub-VLANs specified by vlan-list.
Related commands: display supervlan.
