Network topology icons
Represents a generic network device, such as a router, switch, or firewall.
Represents a routing-capable device, such as a router or Layer 3 switch.
Represents a generic switch, such as a Layer 2 or Layer 3 switch, or a router that supports
Layer 2 forwarding and other Layer 2 features.
Represents an access controller, a unified wired-WLAN module, or the switching engine
on a unified wired-WLAN switch.
Represents an access point.
Represents a mesh access point.
Represents omnidirectional signals.
Represents directional signals.
Port numbering in examples
The port numbers in this document are for illustration only and might be unavailable on your device.

HP 830 Specifications

General

Manageable	Yes
Ports	24 x 10/100/1000 ports, 4 x SFP ports
Power Supply	Internal power supply
Operating Temperature	32°F to 113°F (0°C to 45°C)
Dimensions	17.32 x 10.24 x 1.72 in (44 x 26 x 4.37 cm)
