Nonport side of the 8/40 SAN Switch
The nonport s
ide includes the two redundant power supply fan assemblies and the corresponding status
LEDs. Figure
3 shows the nonport side of the 8/40 SAN Switch.
26451a
1 2 3
4
5
6
7 8
1. Fan (for power sup ply/fan FRU2) 5. Fan (for power supply/fan FRU1)
2. Power sup
ply/fan status LED (for power supply/fan
FRU2)
6. P ower sup
ply/fan status LED (for Power Supply/fan
FRU 1)
3. Power supply c onnector (for power supply/fan
FRU2)
7. Power supply connector (for power supply/fan
FRU 1)
4. Fan (for power supply/fan FRU2) 8. Fan (for power supply/fan FRU1)
Figure 3 N
onpor t side view—8/40 SAN Switch
Activating additional 8/40 SAN Switch por ts
By default, the 8 /40 SAN Switch m odel integrates 24 licensed ports (ports 0 through 23). To enable
additional ports, you must purchase and install the HP Storage Works 8/40 SAN Switch 8 Gb 8 -port
Upgrade LTU (part number T5519A):
• To enable ports 24 through 31, you must purchase and install one upgrade license.
• To enable ports 32 through 40, you must purchase and install a second upgrade license.
See Installing and activating Port Upgrade licenses, page 20.
8/80 SAN Switch features
• Provides the EZSwitchSetup Wizard for easy setup and basic configuration.
• Integrates 1, 2, 4, and 8Gb/s autosensing Fibre Channel switch and router ports.
• Includ
es a system motherboard that features a Freescale MPC8548 Reduced Instruction Set
Computer (RISC) CPU running @ 1.3GHz with integrated peripherals that provides high
performance with low power consumption.
• Ships FICON, FICON Cascading, and FICON Control Unit Port ( CUP) ready.
• Provi
des two hot-swappable, redundant power supp ly FRUs.
• Provides three hot-swappable fan FRUs in an N+1 configuration to provide hardware-redundant
cooling.
• Prov
ides universal ports that self-configure as E_P orts, F_P orts, M_P orts, or FL_Ports. Ex_Ports are
activated on a per-port basis with the optional HP B-series 48-80 Port SAN Switch Integrated
Routing LTU. This license provides native Fibre Channel Routing (FCR) on a per-port basis, rather
than
limiting routing ports to those on a dedicated routing blade or switch. Just like traditional
FCR
, Integrated Routing uses EX_Ports to impor t and export devices between fabrics, enabling
sel
ective device sharing while maintaining remote fabric isolation. See Table 5,page23for
or
dering information.
• Integrates a Universal Serial Bus (USB) port that provides storage for firmware updates, output of
the supportsave command and storage for configuration uploads and downloads.
8Gb SAN Switch hardware reference manual
17
