Table 22 Laser data transmission ranges for the 8/80 SAN Switch
Port speed
Cable size
(microns)
Short wavelength
Long
nl
wavelength
Extended long
wavelength
50
500 m (1,640 ft)
10 km (6.2 miles)
N/A
62.5
300 m (984 ft)
10 km (6.2 miles)
N/A
1Gb/s
9
N/A
10 km (6.2 miles) 80 km (50 miles)
50
300 m (984 ft) N/A N/A
62.5
150 m (492 ft)
10 km (6.2 miles)
N/A
2Gb/s
9
N/A
10 km (6.2 miles)
without an HP Extended
Fabrics license
50 to 100 km with an
HP Extended Fabrics
license
80 km (50 miles)
50
150 m (492 f t)
NA NA
62.5
70 m (230 ft)
NA NA
4Gb/s
9NA
10 km
NA
50
150 m (492 ft) N/A N/A
62.5 2 1 m
N/A N/A
8Gb/s
9
N/A
10 km (6.2 miles)
N/A
Fibre Channel port specifications
The Fibre Channel ports in the 8Gb SAN Switch are compatible with SWL, LWL, a nd ELWL SFP
transceivers. The strength of the signal is determined by the type of transceiver in use.
The ports meet all required safety standards.
The p orts are capable of operating at 1, 2, 4, or 8G bps and a re able to autonegotiate to the maximum
link speed.
POST and boot specifications
The switch performs POST by default each time it is powered on or rebooted or the system is reset. Boot
time with POST is usually about 1 to 3 mi nutes.
POST can be
skipped after subsequent reboots by entering the fastBoot command. For more
informati
on about this command, see theFabric OS command reference manual.
POST
The success/fail results of the diagnostic tests that run during POST can be monitored through LED
activity,theerrorlog,ortheCLI.
nl
POST:
• Conducts preliminary POST diagnostics.
• Initiali
zes the operating system.
• Initializes hardware.
