HP StorageWorks MSA1000 User Manual

Installation Procedures - for all MSA1000 Deployments
47MSA1000 Installation Guide
Connect the power cords to your MSA1000 in the following sequence:
1. Plug one end of the first AC power cord into an uninterruptable power supply
or grounded outlet.
2. Plug the other end of the same AC power cord into one of the power supplies
on the back of the MSA1000.
3. Flip the cord lock lever on the back of the MSA1000 over the power cord to
secure the connection.
4. The power supply automatically senses the input voltage. It is not necessary to
select the correct main voltage.
5. Plug one end of the second AC power cord into another uniterruptable power
supply or grounded outlet.
6. Plug the other end of the second AC power cord into the redundant power
supply on the back of the MSA1000.
Flip the cord lock lever on the back of the MSA1000 over the power cord to
secure the connection.
The MSA1000 has sensed the power and is now in “stand by” mode.

HP StorageWorks MSA1000 Specifications

General

RAID levels	0, 1, 0+1, 5
Certification	Microsoft Cluster Server Certification\\r Hewlett Packard Data Protector\\r VERITAS Backup Exec and NetBackup\\r Legato NetWorker for Windows\\r Computer Associates BrightStor Enterprise Backup
Internal memory	256 MB
Memory clock speed	- MHz
Internal memory type	-
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Supported storage drive interfaces	SCSI
Windows operating systems supported	Yes
Harmonized System (HS) code	84733080

Weight and Dimensions

Depth	52.1 mm
Width	48.3 mm
Height	17.5 mm
Weight	31210 g
