6. Serial port (Factory use only)5. Ethernet port
8. Magazine release hole7. USB port
10. Tape drive LED
9. Pull-out tab containing the serial number and other
product information
11. Tape drive Ethernet port (LTO-5 only)
The device requires a 110/220 volt AC power connection.
Tape drive LED
Each tape drive has a green LED, which indicates that the tape drive is powered on (see Figure 13).
Figure 13 Tape drive LED
.
1. Tape drive LED
Power supply back panel (MSL4048, MSL8084, and
MSL8096)
Figure 14 Power supply LEDs
.
AC power is connected.1. Blue
Fan failure. The fan is running too slow or is defective.2. Yellow
The power supply is producing good power for the Library.3. Green
Features and overview36
