Figure 36 MSL8048 slot numbering with mailslot disabled
.
Figure 37 MSL8096 slot numbering with mailslots disabled
.
When the MSL4048 or MSL8048 mailslot, or the MSL8096 lower-left mailslot is enabled, all of the
storage slot numbers are adjusted, as shown in Figure 38. The storage slots in the other magazines
are renumbered accordingly.
HP StorageWorks MSL2024, MSL4048, MSL8048, and MSL8096 Tape Libraries User and service
guide 65
