HPE ProLiant MicroServer Gen10 Maintenance And Service Guide

Four bay non-hot-plug drive cable assembly spare part
Customer self repair on page 6: Mandatory
Description Spare part number
Four bay non-hot-plug drive cable assembly 874741-001
For more information on the removal and replacement procedures, see Replacing the non-hot-plug
drive cable assembly on page 47.
System board assembly spare parts
Customer self repair on page 6: Mandatory
The system board assembly spare includes the system board attached to the tray, with the heatsink and
the rear USB EMI shield installed.
Description Spare part number
System board assembly with AMD Opteron X3216 APU 874737-001
System board assembly with AMD Opteron X3418 APU P07949-001
System board assembly with AMD Opteron X3421 APU 874738-001
For more information on the removal and replacement procedures, see Replacing the system board
assembly on page 67.
System battery spare part
Customer self repair on page 6: Mandatory
Description Spare part number
3.3-V, 220-mAh lithium battery coin 319603-001
For more information on the removal and replacement procedures, see System battery replacement on
page 65.
DIMM spare parts
Customer self repair on page 6: Mandatory
Description Spare part number
8 GB, single-rank x8 PC4-2400T-E 869537-001
16 GB, dual-rank x8 PC4-2400T-E 869538-001
For more information on the removal and replacement procedures, see Replacing a DIMM on page 51.
Power supply spare part
Customer self repair on page 6: Mandatory
Four bay non-hot-plug drive cable assembly spare part 17

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
