3. Connect the SSD power and SATA cables to the SSD.
Replacing the SSD cables
Replacing the SSD power cable
Procedure
1. Power down the server on page 22
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Disconnect the SSD power cable.
6. Connect the new SSD power cable.
42 Replacing the SSD cables
