Item Description
5 Storage controller
For more information on the removal and replacement procedures, see Replacing an
expansion board on page 53.
6 SSD cable spare parts on page 19*
7 Trusted Platform Module spare part on page 19*
*Not shown
SSD cable spare parts
Customer self repair on page 6: Mandatory
Description Spare part number
SSD power cable, SSD SATA cable 874742-001
For more information on the removal and replacement procedures, see Replacing the SSD cables.
Trusted Platform Module spare part
Customer self repair on page 6: No
Description Spare part number
TPM 2.0 812119-001
SSD cable spare parts 19

HPE ProLiant MicroServer Gen10 Specifications

General

Product Line	HPE ProLiant
Server Type	MicroServer
Maximum Memory	32 GB
Memory Slots	2
Expansion Slots	1 PCIe 3.0 x8 slot
Form Factor	Ultra Micro Tower
Processor	AMD Opteron X3000 series
Memory Type	DDR4 ECC UDIMM
Storage	4 LFF non-hot plug drive bays
Network	2 x 1GbE ports
Power Supply	200W Non-Hot-Plug, Non-Redundant Power Supply
Dimensions	23.5 x 23 x 25.4 cm
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Management	HPE iLO Standard
RAID Support	HPE Smart Array S100i SR Gen10 (RAID 0, 1, 10)
