Clearing the BIOS settings by using the CMOS header
The arrow shown in the steps 6 and 7 illustrations points to the front of the server.
Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Remove the system board assembly on page 25.
6. Remove the jumper from its default position on pins 2 and 3, and place them on pins 1 and 2.
7. After five seconds, remove the jumper from pins 1 and 2, and move it back to the default position on
pins 2 and 3.
8. Install the system board assembly on page 27.
Clearing the BIOS settings by using the CMOS header 75
