FusionModule800 Smart Small Data Center
Installation Guide (Six Fans)
Copyright © Huawei Technologies Co., Ltd.
Figure 3-84 Directly connecting two batteries
When the length of a battery cable is longer than the distance between two battery
terminals, connect the cable in the way shown in Figure 3-85. To prevent misshaping
battery terminals, do not connect the cable in the way shown in Figure 3-86.
Figure 3-85 Correct battery cable connection method
