NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
5 Operation and Maintenance
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-39 Removing a wet film humidifier
1. Hold the blue release sleeve and remove the water inlet pipe.
2. Loosen the two captive nuts on one side of the wet film humidifier and remove the
humidifier.
Step 4 Install the new wet film humidifier in the original position by performing the preceding steps
in reverse order, secure the screws, and connect the hose.
