Figure 5-52 Locking a module
Step 6 Install the network cable and air filter, and close the rear door.
Step 7 Power on the device and tap Startup on the home screen. Ensure that the air conditioner is
running normally without any alarms.
----End
5.4.14 Replacing the T/H Sensor
Prerequisites
The T/H sensor needs to be replaced.
A spare T/H sensor of the same model is available and functional.
Context
The T/H sensor can be maintained only from the rear.
Procedure
Step 1 Tap Shutdown on the controller home screen.
Exercise caution because the device is still energized after it is shut down on the controller
home screen.
Step 2 Open the rear door and remove the air filter.
