NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
5 Operation and Maintenance
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-51 Removing a module
Step 4 Take out the handle and pull out the module from the subrack, as shown by (2) in Figure 5-51.
When installing a new module, ensure that the handle is in the upper part of the module, and
the HUAWEI logo is in the lower left corner of the module.
Step 5 Insert the spare module into the corresponding slot, and flip the clip upwards to lock the
module.
