Figure 6-14 Select path
Step 2 Tap the file where the user saves current data in the Select Path dialog box and tap Next.
Then tap Yes in the displayed dialog box.
Step 3 After the data is successfully exported, Figure 6-15 is displayed. Click Finish.
Figure 6-15 Screen showing that data export has succeeded
Step 4 Click Maint > USB Operations > Remove USB to remove the USB flash drive in safe
mode.
----End
6.11 Clearing the Runtime
Context
Performance value clearance can be performed only after component maintenance. Otherwise
the component may run overtime and degrade performance.
