NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
5 Operation and Maintenance
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Exercise caution because the NetCol5000-A is still energized when it is being shut down on
the LCD.
Step 2 Open the front door and disconnect cables.
Figure 5-55 Disconnecting cables
Step 3 Hold the LCD screen from the front, remove the four screws from the screen using a Phillips
screwdriver, and then remove the LCD screen, as shown in Figure 5-56.
