Huawei NetCol5000-A - Page 32

NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
3 Installation Guide
Issue 01 (2017-07-27)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
24
Table 3-3 Transporting tools
Appearance, specifications, and name
Manual pallet truck
Electrical pallet
truck
Lifting rope (bearing
at least 400 kg)
Lever (bearing at
least 400 kg)
Table 3-4 Pipe connection tools
Appearance, specifications, and name
Cutter
Sealant or seal tape
(for screw threads)
a
Welding torch
Copper-phosphorus
brazing rod
(containing 5%
silver)
Oxygen
Acetylene
Subterrene
Nitrogen
a: The specifications of the sealant or seal tape for screw threads are as follows:

Sealant or seal tape: applies to all pipe material.

Anaerobic metal pipe thread sealant with polytetrafluorethylene (PTFE for short) as the
filler

Maximum seal gap: < 0.5 mm

Pressure resistance: above 1.6 MPa

Compliant with the industry standard JB∕T7311-2008 Technical Specification for the
Application of Anaerobic Glue in Engineering Machinery
