NetCol5000-A 42 kW Air Cooled In-row Precision Air
Conditioner
User Manual
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Naked crimping terminal, OT, 10
mm
2
, M6, 60 A, tin plating, naked
ring terminal
Delivered with the
fittings
Common terminal, single cord end
terminal, conductor cross section 10
mm
2
, length 22 mm, 50 A, insertion
depth 12 mm, ivory
Delivered with the
fittings
Electrical power cable, 600 V/1000
V, ZA-RVV, 5 x 2.5 mm
2
, black
(five cores: brown, black, gray, blue,
and yellow/green), 27 A, outdoor
cable, CE
The length is
determined based on
site survey.
Naked crimping terminal, OT, 2.5
mm
2
, M6, 27 A, tin plating, 16–14
AWG, blue
Delivered with the
fittings
Naked crimping terminal, single-wire
cord end terminal, 2.5 mm
2
, 12.5 A,
tin plating, insertion depth 8 mm,
blue
Delivered with the
fittings
Signal
cable to
the indoor
and
outdoor
units
(optional)
Electrical power cable, 300 V, SJTW,
3 x 16 AWG, black (three cores:
black, white, and green), 10 A,
shielded outdoor cable, UL
The cable applies to the
RS485 communication
connection. The length
is determined based on
site survey.
Signal
cable to
the indoor
and
outdoor
units
(optional)
Electrical power cable, 450 V/750 V,
H07RN-F, 2 x 1 mm
2
, black (two
cores: brown and blue), 10 A, rubber
power cable, VDE
The cable applies to the
dry contact connection.
The length is
determined based on
site survey.
Cord end
terminal
for the
cable
Naked crimping terminal, single-wire
cord end terminal, 1.5 mm
2
, 7.5 A,
tin plating, insertion depth 8 mm, red
Delivered with the
fittings
Teamwork
control
network
cable
(optional)
Symmetric twisted-pair cable, 100
ohm, enhanced category 5 cable,
aluminum foil shield, 0.52 mm, 24
AWG, eight cores, four pairs of
PANTONE 430U, equipped with
plug
