5.25 Screw fasteners
All screws are made from stainless material or rustproofed with zinc plating. Article numbers are to be found in the
separate Spare Parts List.
Table 3: Screw fasteners
Fastener Hardware Tool Tightening
torque (Nm)
Husqvarna
Automower
®
310/315
GARDENA R100Li,
R100LiC,R130Li,
R130LiC, R160Li
Husqvarna Automower
®
310/315
GARDENA R100Li, R100LiC,
R130Li, R130LiC, R160Li
Circuit board holder Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Display cover Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Brush mounting Screw, M6 x 8 mm - 4 mm socket head 2
Magnet holder, body Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Service plug Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,2
Front wheel Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1,2
Chassis Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Rear collision column Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,5
Wheel motor unit Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Battery cover - Screw, M4 x 12 mm Torx 20 1,8
Antenna plate Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1,5
Wheel nut Nut M16 Nut M16 24 mm hexagon 18
Ball bearing retainer, skid
plate
Screw M6 x 8 mm Screw M6 x 8 mm 4 mm socket head 5,0
Cutting system Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Weight holder - Screw, 5 x 16 mm Torx 20 1,8
Front loop sensor board Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
CS cover *) Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1
Rear bumper Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Front support Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1,2
Rear support Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1,2
Smartsystem circuit board - Screw, 5 x 16 mm Torx 20 1,8
Screw, height adjustment Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 1,8
Front collision column to
chassis
Screw, 5 x 16 mm Screw, 5 x 16 mm Torx 20 3
Battery holder Screw, 5 x 16 mm - Torx 20 1,8
Snap-on fastener, front
collision column
Screw M6 Screw M6 13 mm hexagon 2
CS lid *) Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 0,8
CS contacts *) Screw, grey 4 x 14 mm Screw, grey 4 x 14 mm Torx 20 1
Skid plate Screw, grey 4 x 14 mm - Torx 20 1,5
*) CS - Charging Station
