Husqvarna AUTOMOWER 310 Technical Manual

English - 59
5.2 Disassembling and
assembling the robotic
lawnmower
Clean any grass and dirt from the
robotic lawnmower before you begin
disassembling.
IMPORTANT INFORMATION
5.2.1 Disassembling the body
The body is tted to the chassis using 3 quick-
mounted, snap-on brackets. The charging cable
fastened to the body’s charging strip must be
disconnected to be able to remove the body entirely
from the chassis.
1. Set the main switch to position 0.
2. Clean the area around the grommet for the
charging cable found at the very front under
the mower.
3. Pull out the rubber grommet on the charging
cable and carefully loosen the connector.
4. Loosen the body from the chassis by lifting
the body one corner at a time while holding
the chassis in place.
5.2.2 Disassembling the chassis
The chassis consists of upper and lower sections.
These are screwed together with 14 screws.
1. Disassemble the body. See 5.2.1
Disassembling the body on page 59.
2. Remove the cutting height adjustment knob.
3. Loosen all 14 screws (Torx 20).
5. REPAIR INSTRUCTIONS
TH_1158203_310_315_GARDENA_US.indd 59 2016-05-11 10:16:22

Husqvarna AUTOMOWER 310 Specifications

General

Cutting Width	22 cm
Cutting Height Min	20 mm
Cutting Height Max	50 mm
Battery Type	Li-ion
Typical Charging Time	60 min
Typical Mowing Time per Charge	70 min
Maximum Incline Within the Working Area	40%
Working Area Capacity	1000 m²
Battery Capacity	2.1 Ah
Weight	9.4 kg
Battery Voltage	18 V
Operating Time	70 min
Maximum Area	1000 m²
Weather Resistance	Yes
Smart Connectivity	No
Blade Type	Pivoting razor blades
