Hypertherm Powermax 85 Service Manual

Torch SeTup
powermax 65/85 Service Manual 3-13
6
5
A
4
5
A
220955
Deflector
220854
Retaining cap
220941
Nozzle
220819
Nozzle
220857
Swirl ring
220842
Electrode
Mechanized unshielded consumables: Powermax65
6
5
A
4
5
A
8
5
A
6
5
A
4
5
A
8
5
A
220817
Shield
220817
Shield
220854
Retaining cap
220857
Swirl ring
220857
Swirl ring
220842
Electrode
220842
Electrode
220953
Ohmic-sensing
retainingcap
Mechanized shielded consumables: Powermax85
Mechanized shielded with ohmic consumables: Powermax85
220941
Nozzle
220941
Nozzle
220819
Nozzle
220819
Nozzle
220816
Nozzle
220816
Nozzle

Hypertherm Powermax 85 Specifications

General

Gas Supply	Clean, dry, oil-free air or nitrogen
Cooling Method	Fan-cooled
Input Voltage	200-600V, 3-phase
Current Output	25-85 A
Duty Cycle	60% @ 85 A
Recommended Gas Inlet Flow Rate/Pressure	6.7 scfm @ 85 psi
Cutting Capacity (Recommended)	1" (25 mm)
Gas Type	Air/Nitrogen
