Torch SeTup
3-14 powermax
65/85
Service Manual
Gouging consumables
220854
Retaining cap
220857
Swirl ring
220842
Electrode
220798
Shield
220797
Nozzle
FineCut
®
unshielded consumables
FineCut
®
shielded consumables
220854
Retaining cap
220953
Retaining cap
220857
Swirl ring
220857
Swirl ring
220842
Electrode
220842
Electrode
220955
Deflector
220948
Shield
220930
Nozzle
220930
Nozzle
6
5
A
4
5
A
8
5
A
220955
Deflector
220854
Retaining cap
220857
Swirl ring
220842
Electrode
Mechanized unshielded consumables: Powermax85
220941
Nozzle
220819
Nozzle
220816
Nozzle
