HySecurity UL 325 - Setting Sensor Logic for Entrapment Protection; Eye Close Logic Configuration; Eye Open Logic Configuration; Gate Edge Logic Configuration

Table 6: Setting the Sensor Logic
External entrapment protection sensors can be wired to any one of the three sensor inputs on the HySecurity Controller.
The sensor logic, such as Eye Close Logic (EC), Eye Open Logic (EO) and Gate Edge Logic (GR) remain accessible in
the Installer Menu, if the corresponding sensor type is installed, and determine how the gate operator will react when a
monitored sensor is activated.
NOTE: Default settings shown in Bold.
Installer Menu Setting Options Menu Tasks & Explanations
STC Wire
Connections
EC 0 STOP ONLY
EYE CLOSE LOGIC
0 = Close eye stops only
1 = Two second reversal to open
on swing, slide, or vertical gates.
Reverse to full open with barrier
gates, StrongArm M30 and
StrongArm M50.
2 = Reverse to full open.
If the close photo eye is triggered, the default
setting is non-reversal while the gate is traveling
in the close direction. When triggered, with the
optional setting of EC 1, the gate pauses and
reverses it's direction for a 2-second interval,
and then resumes moving in the close direction
if the photo eye clears within 5 seconds. (See
exception for barrier arms.) A setting of EC 2
causes the gate to reverse and travel full open
when triggered.
Sensor 1, 2, or 3
Sensor COM
COM
+24V
EO 0 STOP ONLY
EYE OPEN LOGIC
0 = Open eye stops only
1 = Two second reverse to close
If the open photo eye is triggered, the default
setting is non-reversal while the gate is traveling
in the open direction. When triggered, with the
optional setting of EO 1, the gate pauses and
reverses it's direction for a 2-second interval, and
then resumes moving in the open direction if the
photo eye clears within 5 seconds.
Sensor 1, 2, or 3
Sensor COM
COM
+24V
GR 0 FULL OPEN
GATE EDGE LOGIC
0 = Edge reverses fully open
1 = Two second reversal only
The default setting is to reopen fully if the edge
sensor is triggered while closing. The optional
setting of GR 1 sets the gate to a 2-second
reversal if triggered while closing.
Sensor 1, 2, or 3
Sensor COM
+24V
10K resistor
(Edge)
SR 1 REVERSE 25
REVERSAL LOGIC
0 = IES reverses fully open
1 = Two second reversal only
If the inherent sensor is triggered, the default
setting reverses the gate travel for a 2-second
duration. The optional setting of SR 0 will cause
the gate to reopen fully if triggered while closing.
N/A
PC 0 NO INPUT
PHOTO EYE OUTPUT
0 = Normally Open NO input
1 = Normally Closed NC input
(monitored)
Changes occurring in 2016.
The default setting is for photo eyes with
Normally Close outputs. When set for NC, the
connection is monitored and any short circuit
fault will generate a FAULT 2 (FAL2) alert. Press
the Stop or Reset button to clear.
See NOTE.
EYE Close
EYE COM
4 wires total:
COM
+24V
COM
PHOTO EYE
CLOSE
GC 0 NO INPUT
GATE EDGE OUTPUT
0 = Normally Open NO input
1 = Normally Closed NC input
(monitored)
Changes occurring in 2016.
The default setting is edge sensor with Normally
Closed (NC) output. The optional setting of 0
requires an (NO) output.
See NOTE.
EDGE SENSOR
COM
4 wires total:
COM
+24V
COM
EDGE
NOTE: The shaded Installer Menu items do not appear when Build Year is set to 2 (BY 2), post-2016. Exceptions exist for barrier
arms, CRASH products, operators set to pre-2016 and Usage Class 4 provisions.
