IAI ROBO Cylinder RCS4- SA4C User Manual

1.2 Specifications
1-26
1. Specifications
[Payload by Acceleration]
At low load capacity, the acceleration/deceleration can be increased.
Lead 48 Lead 30
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
8 8 8 5 ‒ ‒ ‒ ‒ ‒ ‒ 30 25 20 15 ‒ 12 12 10 8 ‒
Lead 20 Lead 10
Horizontal Vertical Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
60 40 30 20 ‒ 20 20 18 15 ‒ 80 80 70 60 ‒ 35 35 35 30 ‒
Lead 5
Horizontal Vertical
0.3 0.5 0.7 1.0 1.2 0.3 0.5 0.7 1.0 1.2
90 90 70 ‒ ‒ 45 45 35 ‒ ‒
Caution
Do not attempt to configure settings for acceleration/deceleration above the specifications.
This may lead to vibration, breakdown, or shortened product life.
