Removal/Replacement (cont.)
5
1/4"
Diskette Drive (cont.)
Servo Board Replacement 3-29
IBM 80 CPS Printer
Control Cards
Write Protect Switch Removal 3-30
Write Protect Switch Replacement 3-31
Access Cover Removal 3-32
Base Cover Removal 3-33
Base Cover Replacement 3-34
Carriage Belt Adjustment 3-35
Carriage Belt Removal 3-37
Carriage Belt Replacement 3-40
Carriage Drive Assembly Removal 3-42
Carriage Drive Assembly Replacement 3-43
Control Circuit Card Removal 3-45
Control Circuit Card Replacement 3-48
Driver circuit Card Removal
3-51
Driver circuit Card Replacement 3-53
Control Panel Removal 3-54
Control Panel Replacement 3-54
Forms Feed Knob Removal 3-55
Forms Rack Removal 3-56
Forms Tractor Removal 3-57
Forms Tractor Replacement 3-58
Fuse Removal 3-59
Fuse-Filter Card/Power Cord Removal 3-60
Fuse-Filter Card/Power Cord Replacement 3-61
Heat Sink/Power Transistor Assembly Removal 3-62
Heat Sink/Power Transistor Assembly Replacement 3-63
Intermediate Gear Removal 3-64
Intermediate Gear Replacement 3-65
Left Margin Sensor Adjustment 3-66
Left Margin Sensor Removal 3-72
Left Margin Sensor Replacement 3-
73
Power Tmsformer Removal 3-74
Power Transformer Replacement 3-75
Print Head Gap Adjustment
3-
76
Print Head Removal 3-77
Print Head Replacement 3-79
Print Mechanism Assembly Removal 3-80
Print Mechanism Assembly Replacement 3-81
Ribobn Shield Removal 3-84
Ribbon Shield Replacement 3-85
