Labels
On Backing: One-part continuous perforated fan-fold back form. Labels must be
placed at least 1/6 inch (0.42 cm) from the fan-fold perforation.
Backing adhesive must not be squeezed out during printing.
Sheet Size: 3 to 17 inches (7.62 to 43.18 cm) wide*, including the two standard
perforated tractor feed strips. A maximum sheet length of 16 inches
(40.64 cm) between top and bottom perforations.**
Thickness: Not to exceed 0.025-inch (0.064 cm), including backing sheet.
*On pedestal models, when using the rear paper exit, the maximum form width is
16 inches (40.64 cm).
**On cabinet models, forms longer than 12 inches can be used by opening the front
and rear printer doors.
Printer Dimensions and Weight
Cabinet Models
Height: 41 inches (103.3 cm)
Width: 27 inches (68.6 cm)
Depth: 29 inches (73.7 cm)
Weight:
225 lbs. (102.1 kg) unpackaged
237 lbs. (112. kg) unpackaged with power stacker
285 lbs. (129.3 kg) packaged
297 lbs. (139 kg) packaged with power stacker
Pedestal Models
Height: 35.5 inches (90.2 cm)
Width: 24.6 inches (62.5 cm)
Depth: 30 inches (76.2 cm)
Weight:
120 pounds. (54.4 kg) unpackaged
160 pounds. (72.6 kg) packaged
252 Infoprint 6500 User’s Manual
