IBM 6500 - Printer Dimensions

Printer Dimensions
27.0 in
(68.84 cm)
29.0 in
(73.7 cm)
83.0 in
(210.8 cm)
27.0 in
(68.6 cm)
27.0 in
(68.6 cm)
41.0 in
(104 cm)
57.5 in
(146.1 cm)
C2qu0001
Figure 2. Exploded View of Cabinet Model Printer Dimensions
42.5 in
(107.8 cm)
59.0 in
(149.9 cm)
27.0 in
(68.6 cm)
83.0 in
(210.8 cm)
27.0 in
(68.84 cm)
32.5 in
(82.6 cm)
27.0 in
(68.6 cm)
32.0 in
(81.3 cm)
C2qu0002
Figure 3. Exploded View of Cabinet Model with Power Paper Stacker Printer Dimensions
Chapter 2. Installation 15
