Table 3. Firmware Error Codes. (continued)
Error Code Description Action / Possible Failing FRU
4BA10002 SSC SRAM fail Go to “MAP 1540: Minimum
Configuration” on page 63.
4BA10003 The service processor hardware self-test
failed.
Replace the system board.
Location: P1
(See note 3 on page 115.)
4BA10004 The service processor firmware failed. 1. Restore or update the service
processor firmware.
2. Replace the system board.
Location: P1
(See note 3 on page 115.)
4BA10005 I²C path fail. 1. Replace the system board.
Location: P1
(See note 3 on page 115.)
2. Replace the processor card.
Location: P1-C1.
Location: P1-C2
4BA10832 Error while attempting a flash update. 1. Power-off, then power-on the
system unit.
2. Do the following flash recovery
procedure:
a. Insert a newly formatted DOS
diskette loaded with service
processor firmware into the
diskette drive. The file name
must be
spflash.img
.
b. Shut down the system unit and
unplug the power cable.
c. Plug in the power cable,
power-on the system unit.
3. Retry item 2 with a newly
formatted DOS diskette.
4. Replace the system board.
Location: P1
(See note 3 on page 115.)
4BA11111 Problem with system board. Replace the system board.
Location: P1
(See note 3 on page 115.)
4BA80013 NVRAM access failure. 1. Remove, then reapply AC power.
The service processor settings
(modem speeds and call-out
numbers, for example) may have
to be reentered
2. Call service support.
174 Service Guide
