3. Press inward on one end button and lift upward on that end of the button
frame.
4. Then, press the center button and continue to lift upward on the frame.
5. Press on the opposite end button to freely lift the button assembly.
6. To replace, reverse this procedure.
Note: Be sure to align the control button holes with the holes in the bottom
cover.
Removing the LCD
Follow these steps to remove the LCD:
1. Switch OFF the power to the IBM AnyPlace Kiosk. Unplug the power cord
from the external power source.
2. Follow the instructions in “Removing the front cover/touch assembly” on page
55.
Removing and replacing FRUs
Chapter 4. Removing and replacing FRUs 59
