Models and features
This section describes the model numbering and optional features.
Administrative models and other models that represent different service repair
options are not listed. See your IBM representative for a complete list.
The model scheme is as follows: 4838-XYZ.
X Indicates the screen size: 5 for 15 inch, 7 for 17 inch, and 9 for 19 inch
Y Processor type: either 1= AMD Sempron, and 2 = AMD Turion
Z Indicates the preinstalled software, if any:
0 None
E Windows
®
Embedded for Point of Sale (WEPOS), Windows XP or
Windows Vista
For example, a model 4838-720 would be a 17" screen size with Turion processor
and no preload.
Table 1. Summary of characteristics and weight by model.
Characteristics Model 5xx Model 7xx Model 9xx
Height 325.6 mm (12.82 in.) 367.5 mm (14.47 in.) 398.5 mm (15.69 in.)
Width 368.6 mm (14.51 in.) 402.0 mm (15.83 in.) 440.6 mm (17.35 in.)
Depth 72.8 mm (2.87 in.) 78.3 mm (3.08 in.) 82.8 mm (3.26 in.)
Weight 6.45 kg (14.2 lbs.) 8.27 kg (18.2 lbs.) 9.31 kg (20.5 lbs.)
Note: See Appendix B, “Product dimensions,” on page 81 for more detailed
dimensions including the options.
Table 2. Feature descriptions
Features
LCD 15" TFT
1024 x 768
2 bulb
17" TFT
1280 x 1024
4 bulb
19" TFT
1280 x 1024
4 bulb
CPU AMD Mobile Sempron 3500+ 1.8 Ghz or AMD Mobile Turion 64 X2 TL-56 1.8 Ghz with 1 Ghz Front
Side Bus (FSB)
Memory 4 GB maximum system memory using 512 MB, 1 GB or 2 GB DDR2 667 (PC2-5300) SO-DIMMs in any
combination
Touch Infrared with Unintentional Touch feature (RS 232 interface - COM5)
Mass
storage
80 GB 3.5" SATA II 7200 RPM
160 GB 3.5" SATA II 7200 RPM, 4 GB modular flash drive (optional)
Video
v VIA integrated Chrome 9 graphics
v External VGA (HD-15) output supporting dual independent video and mirrored video
Video
memory
v 256 MB max, shared dynamically from system memory
Slots 1 ExpressCard (supports 34 mm or 54 mm)
Introducing the IBM AnyPlace Kiosk
2
IBM AnyPlace Kiosk 4838
