7. Is a scanner installed?
Yes Remove the scanner wire slot cover.
No Check that the scanner wire slot cover is installed.
8. Hook the unit onto the tabletop mount and tighten the mount thumb screw
(A in picture 3 in Figure 14 on page 22) to secure the unit to the mount.
9. Install the base cover, then the upper cover.
10. Retain the AC adapter cable with the cable harness located on the tabletop
mount (B in Figure 14 on page 22).
11. Place the IBM 4838 unit in the desired location.
Notes:
1. You can adjust the tilt angle of the unit for optimum performance.
2. The mount can be bolted to the counter top, using the hole provided. The bolt
hole will allow you to use up to a #10 or M5 bolt.
3. A notebook computer type lock, which is compatible with the Kensington Lock
slot, can also be used to secure the mount. The lock slot is located under the
base cover.
Wall mount
Follow the procedures described in Chapter 3, “Mounting the IBM AnyPlace Kiosk
to the wall,” on page 27.
Powering on
The following notes will assist you during powering on:
Notes:
1. Your new IBM AnyPlace Kiosk ships with a control button cover. The purpose
of the control button cover is to limit access to the control buttons. This feature
is especially desirable if the system is located in a public environment. Install
this part after you power on and adjust the image.
2. Three small holes (see L, M, and N in Figure 15 on page 24 for the
approximate location) in the control button cover allow you to actuate the
control buttons. Use a paper clip or other small tool to actuate the button.
3. A paper clip is required to open or remove the cover. See “Installing the control
button cover” on page 24 for additional information.
Installing the IBM AnyPlace Kiosk
Chapter 2. Installing the IBM AnyPlace Kiosk 23
