Asm–
Index
Part
Number Units Description
1–1 44V0723 1 Door kit, cable cover (includes both door assemblies, hinge pin, quarter-turn latches)
–2 44V0728 1 Cover, extended ExpressCard cover
–3 44V0758 1 Door, HDD (includes plastic, metal, screw, retainer; all assembled)
–4 44V0757 1 Door assembly, side (includes side access door with flat mini-door assembled and
screw/retainer assembled)
–5 40N6636 1 MSR, 3-track
–5 40N6640 1 MSR, JUCC
–6 44V0737 1 CPU fansink
–7 44V0732 1 Card, wireless (includes installation instructions; country dependent)
–7 44V0780 1 Card, wireless (includes installation instructions; country dependent)
–7 44V0782 1 Card, wireless (includes installation instructions; country dependent)
–7 44V0786 1 Card, wireless (includes installation instructions; country dependent)
–8 44V0754 1 Flash drive, 4 GB
–9 44V0742 1 Processor, Sempron
–9 44V0743 1 Processor, Turion
–10 44V0733 1 System board (includes I/O shield) - for use only on system serial numbers KK099
and below.
–10 44V0759 System board, S3 power mode enabled (includes I/O shield)
–11 44V0746 1 Memory module, 0.5 GB, DDR2, 667 MHz, unbuffered SO-DIMM
–11 44V0747 1 Memory module, 1 GB, DDR2, 667 MHz, unbuffered SO-DIMM
–11 44V0756 1 Memory module, 2 GB, DDR2, 667 MHz, unbuffered SO-DIMM
–12 45P6222 1 Battery, coin cell
–13 44V0736 1 HDD fan assembly (includes attached bracket)
–14 44V0725 1 I/O shield assembly
–15 44V0775 1 Backlight inverter card, 15 in. LCD
–15 44V0776 1 Backlight inverter card, 17 in. / 19 in. LCD
–16 44V0717 1 Scanner, line
–16 44V0718 1 Scanner, omni (without scanner shield)
–16 44V0719 1 Scanner window
–16 44V0766 Scanner shield, omni
–17 44V0722 1 Door, control button cover
–18 44V0763 1 Bottom cover assembly, 15 in. LCD (includes assembled control buttons)
–18 44V0764 1 Bottom cover assembly, 17 in. LCD (includes assembled control buttons)
–18 44V0765 1 Bottom cover assembly, 19 in. LCD (includes assembled control buttons)
–19 57P4199 1 Buttons, control
–20 44V0734 1 Card, control (includes attached infrared sensor LED housing
–21 42J2733 2 Speakers
–22 44V0739 1 Antenna, top (gray cable)
–23 44V0738 1 Antenna, side (black cable)
–24 44V0740 1 Antenna, top (white cable)
–25 44V0948 1 HDD assembly, 80 GB (includes assembled bracket and screws)
–25 44V0949 1 HDD assembly, 160 GB (includes assembled bracket and screws)
–25 44V0947 1 HDD mounting hardware
–26 44V0772 1 LCD shield assembly, 15 in. (includes baffles, and so on.)
–26 44V0773 1 LCD shield assembly, 17 in. (includes baffles, and so on.)
–26 44V0774 1 LCD shield assembly, 19 in. (includes baffles, and so on.)
–27 44V0769 1 LCD assembly, 15 in. (includes attached EDID card)
–27 44V0770 1 LCD assembly, 17 in. (includes attached EDID card)
–27 44V0771 1 LCD assembly, 19 in. (includes attached EDID card)
–28 44V0760 1 Front assembly, 15 in. LCD
–28 44V0761 1 Front assembly, 17 in. LCD
–28 44V0762 1 Front assembly, 19 in. LCD
–29 42V3897 1 MSR hole plug
Assembly 1: (continued)
Appendix A. Field-replaceable units 77
||||
||||
||||
||||
||||
||||
||||
||||
|
||||
||||
||||
