© Copyright IBM Corp. 2010. All rights reserved. 183
Draft Document for Review March 28, 2011 12:24 pm 7914Admin_Summary.fm
Chapter 7. Administration - Summary Tab
In this chapter, we give you an overview of the Summary tab of the IBM System Storage DS
(Subsystem Management) window.
We explain:
How to monitor the basic status of your storage subsystem
How to get a basic overview of your installed hardware components
How to get a basic information about the current logical configuration
The first tab on the left side of Subsystem Manager in Tab area is Summary tab. Figure 7-1
on page 184 shows a simply configured system that is running in an optimal status.
The Summary tab is divided into six boxes, which we describe in the following sections:
7.1, “Status” on page 185
7.2, “Hardware Components” on page 187
7.3, “Capacity” on page 188
7.4, “Hosts & Mappings” on page 189
7.5, “Arrays & Logical Drives” on page 191
7.6, “Information Center” on page 191
