Index Description
CRU part
number (Tier 1)
CRU part
number (Tier 2)
Thermal grease kit 41Y9292
Alcohol wipes 59P4739
Microprocessor installation tool 00AE535
CMA kit, 1U 00KA595
CMA kit 49Y4817
COM port bracket 00KC965
Adapter, DVI to VGA adapter 25R9043
Half high LTO Gen 6 SAS tape drive 35P1049
USB optical wheel mouse 39Y9875
QLogic 10Gb virtual fabric and SR optical transceiver 42C1816
Brocade 10Gb SFP+ SR optical transceiver 46C9297
USB backplate 44E8877
Internal RDX USB 3.0 drive dock 46C2346
External RDX USB 3.0 drive dock 46C2347
10Gb SFP + SR transceiver 46C3449
RDX 320 GB cartridge 46C5394
RDX 500 GB cartridge 46C5395
External RDX power adapter 81Y8905
UltraNav keyboard USB 94Y6108
US E 103P-RoHS keyboard 94Y6050
Label, system service 00KF684
Front USB assembly, ten 2.5-inch hard disk drives 00KF694
Structural parts
Structural parts are not covered by the IBM Statement of Limited Warranty. The
following structural parts are available for purchase from the retail store.
Table 23. Structural parts, Type Type 5463
Index Description Part number
1 Top cover 00KF667
2 Power supply bay filler 94Y7610
12 Chassis, four 3.5-inch hard disk drives 00KF662
12 Chassis, eight 2.5-inch hard disk drives 00KF663
12 Chassis, ten 2.5-inch hard disk drives 00KF664
19 Media cage, ten 2.5-inch hard disk drives 00KF678
20 Filler, DVD drive 00KF416
22 Filler, 3.5-inch hot-swap hard disk drive 69Y5364
22 Filler, 3.5-inch simple-swap hard disk drive 69Y5368
27 Filler, 2.5-inch hard disk drive bay 00FW856
27 Filler, 2.5-inch hard disk drive bay (rear) 00KF683
33 Battery holder 00KF677
Chapter 4. Parts listing, IBM System x3550 M5 Type 5463 117
