Note: Make sure that the newly-installed fan aligns horizontally with other
correctly-seated fans for proper installation.
6. Reinstall the cover (see “Replacing the cover” on page 127).
7. Slide the server into the rack.
Removing a power supply
Use this information to remove a power supply.
Removing a hot-swap ac power supply
Use this information to remove a hot-swap ac power supply.
About this task
When you remove or install a hot-swap power supply, observe the following
precautions.
Statement 5
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current from
the device, ensure that all power cords are disconnected from the power source.
1
2
Figure 113. Fan installation (2)
196 IBM System x3550 M5 Type 5463: Installation and Service Guide
