IBM System x3550 M5 Type 5463 User Manual

6. Remove the adapter, if one is present, from the PCI riser-card assembly (see
“Removing an adapter” on page 177).
7. Set the adapter and the PCI riser-card assembly aside.
Results
If you are instructed to return the PCI riser-card assembly, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
Replacing a PCI riser-card assembly
Use this information to replace a PCI riser-card assembly.
About this task
Note: PCI riser-card brackets must be installed even if you do not install an
adapter.
The following table lists the supported PCI riser-card assembly configurations in
the server.
Table 26. Configuration 1
Configuration 1
Configura
tion
Number of
micropro
cessors
installed
PCI riser-card assembly connector 1
on system board
PCI riser-card assembly connector 2 on system
board
Slot 1 Slot 2 Slot 3
v Three
low-
profile
slots
One x1/x4/x8/x16 low-profile x1/x4/x8 low-profile x1/x4/x8 low-profile
1U PCIe Riser 2 assembly
(2 x low profile; x8 or x16)
1U PCIe Riser 1 assembly
(1x low profile; x16)
Bracket
Figure 89. PCI riser-card assembly removal (4)
172 IBM System x3550 M5 Type 5463: Installation and Service Guide

IBM System x3550 M5 Type 5463 Specifications

General

Form Factor	1U rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 product family
Memory	Up to 1.5TB DDR4
Storage	Up to 8x 2.5" HDD/SSD or 4x 3.5" HDD
RAID Support	RAID 0, 1, 10
Network Interface	Four integrated Gigabit Ethernet ports (10/100/1000 Mbps)
Expansion Slots	Up to 3 PCIe 3.0 slots
Power Supply	Dual redundant hot-swap 550W, 750W, or 900W
Operating Systems Supported	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
