IBM System x3550 M5 Type 5463 User Manual

3. Remove the RAID adapter battery or flash power module (see “Removing a
RAID adapter battery or flash power module” on page 130).
4. To remove the holder, press the blue release tab; then, slide the holder away
from the chassis.
Results
If you are instructed to return the RAID adapter battery or flash power module
holder, follow all packaging instructions, and use any packaging materials for
shipping that are supplied to you.
Replacing a RAID adapter battery or flash power module
holder
Use this information to replace a RAID adapter battery or flash power module
holder.
About this task
To install a RAID adapter battery or flash power module holder, complete the
following steps:
Note: The following steps only applies to 2.5-inch hard disk drive server models.
The RAID adapter battery or flash power module holder cannot be removed for
3.5-inch hard disk drive server models.
Procedure
1. Read the safety information that begins on “Safety” on page vii and
“Installation guidelines” on page 122.
Blue release tab
Figure 47. RAID adapter battery or flash power module holder removal
Chapter 5. Removing and replacing components 139

IBM System x3550 M5 Type 5463 Specifications

General

Form Factor	1U rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 product family
Memory	Up to 1.5TB DDR4
Storage	Up to 8x 2.5" HDD/SSD or 4x 3.5" HDD
RAID Support	RAID 0, 1, 10
Network Interface	Four integrated Gigabit Ethernet ports (10/100/1000 Mbps)
Expansion Slots	Up to 3 PCIe 3.0 slots
Power Supply	Dual redundant hot-swap 550W, 750W, or 900W
Operating Systems Supported	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
