Ten 2.5-inch hot-swap hard disk drive server configuration:
Four 3.5-inch hot-swap or simple-swap hard disk drive server configuration:
Media cage
Video connector
Screws
Figure 151. Front video connector assembly removal for eight 2.5-inch hot-swap or
simple-swap hard disk drive server configuration
Media cage
Video connector
Screws
Figure 152. Front video connector assembly removal for ten 2.5-inch hot-swap hard disk
drive server configuration
Chapter 5. Removing and replacing components 231
