Ten 2.5-inch hot-swap hard disk drive server configuration:
Four 3.5-inch hot-swap or simple-swap hard disk drive server configuration:
Media cage
Video connector
Screws
Figure 154. Front video connector assembly installation for eight 2.5-inch hot-swap or
simple-swap hard disk drive server configuration
Media cage
Video connector
Screws
Figure 155. Front video connector assembly installation for ten 2.5-inch hot-swap hard disk
drive server configuration
Chapter 5. Removing and replacing components 233
