IBM System x3550 M5 Type 5463 User Manual

14. Loosen the two thumbscrews (one is near PCI slot 1 and one is near PCI slot
2).
15. Grasp the system board handles and slide the system board toward the front
of the server until it stops.
Note: Make sure that the system board disengage from all system-board
standoffs.
16. Slightly push the system board toward the hot-swap fans; then, grasp the
system board handles and carefully lift it up from the chassis, being careful
not to damage any surrounding components.
Battery holder
Figure 195. Battery or power module holder location for 3.5-inch hard disk drive server
models
System board handle
System board handle
Thumbscrew
Thumbscrew
Figure 196. Thumbscrews disengagement
262 IBM System x3550 M5 Type 5463: Installation and Service Guide

IBM System x3550 M5 Type 5463 Specifications

General

Form Factor	1U rack
Memory Slots	24 DIMM slots
Processor	Intel Xeon E5-2600 v3/v4 product family
Memory	Up to 1.5TB DDR4
Storage	Up to 8x 2.5" HDD/SSD or 4x 3.5" HDD
RAID Support	RAID 0, 1, 10
Network Interface	Four integrated Gigabit Ethernet ports (10/100/1000 Mbps)
Expansion Slots	Up to 3 PCIe 3.0 slots
Power Supply	Dual redundant hot-swap 550W, 750W, or 900W
Operating Systems Supported	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
