IBM System x3850 X5 Implementation Guide

92 IBM eX5 Implementation Guide
Table 3-22 lists the 2.5-inch SAS 10K and 15K RPM disk drives and the 2.5-inch SSD that are
supported in the x3850 X5. These drives are supported with the SAS hard disk backplane,
59Y6135.
Table 3-22 Supported 2.5-inch SAS drives and 2.5-inch SSDs
Table 3-23 lists the 2.5-inch Nearline SATA 7.2K drives that are supported in the x3850 X5.
These drives are supported with the SAS hard disk backplane, part number 59Y6135.
Table 3-23 Supported 2.5-inch Nearline SATA drives
The 2.5-inch drives require less space than 3.5-inch drives, consume half the power, produce
less noise, can seek faster, and offer increased reliability.
46M0916 3877 ServeRAID M5014 SAS/SATA Controller
46M0969 3889 ServeRAID B5015 SSD
46M0930 5106 IBM ServeRAID M5000 Advance Feature Key: Adds RAID-6,
RAID-60, and SED Data Encryption Key Management to the
ServeRAID M5014, M5015, and M5025 controllers
81Y4426 A10C IBM ServeRAID M5000 Performance Accelerator Key: Adds Cut
Through I/O (CTIO) for SSD FastPath optimization on ServeRAID
M5014, M5015, and M5025 controllers
a. The battery is not included with the ServeRAID M5015.
Part number Feature code Description
42D0632 5537 IBM 146 GB 10K 6 Gbps SAS 2.5-inch SFF Slim-HS HDD
42D0637 5599 IBM 300 GB 10K 6 Gbps SAS 2.5-inch SFF Slim-HS HDD
42D0672 5522 IBM 73 GB 15K 6 Gbps SAS 2.5-inch SFF Slim-HS HDD
42D0677 5536 IBM 146 GB 15K 6 Gbps SAS 2.5-inch SFF Slim-HS HDD
43W7714 3745 IBM 50 GB SATA 2.5-inch SFF Slim-HS High IOPS SSD
Part number Feature code Description
42D0747 5405 IBM 160GB 7200 NL SATA 2.5'' SFF Slim-HS HDD
42D0752 5407 IBM 500GB 7200 NL SATA 2.5'' SFF Slim-HS HDD
Compatibility: As listed in Table 3-22, the 2.5-inch 50 GB SSD is also supported with the
standard SAS backplane and the optional SAS backplane, part number 59Y6135. It is
incompatible with the 1.8-inch SSD eXFlash backplane, part number 59Y6213.
A typical configuration can be two 2.5-inch SAS disks for the operating system and two
High IOPS disks for data. Only the 2.5-inch High IOPS SSD disk can be used on the SAS
backplane. The 1.8-inch disks for the eXFlash cannot be used on the SAS backplane.
Part number Feature code Description

IBM System x3850 X5 Specifications

General

Processor Cores	Up to 10 cores per processor
Chipset	Intel 7500
Hard Drive Interface	SAS/SATA
Processor	Intel Xeon E7-4800 series, Intel Xeon E7-8800 series
Memory Slots	64 DIMM slots
Storage	Up to 16 x 2.5" hot-swap SAS/SATA HDDs or SSDs
RAID Support	RAID 0, 1, 5, 6, 10
Network Interface	Integrated Gigabit Ethernet
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware vSphere
Form Factor	4U Rack
